ASUS RS700A-E13-RS4U-2KW10 1U Rackmount Barebone Server Dual AMD EPYC 9005 SP5 Supported 24x DDR5 ECC RAM Slots4x Hot-Swap NVMe/SATA/SAS Dual 10GbE 2000W Redundant PSU
Model #: RS700A-E13-RS4U-2KW10
Item #: SYSASU2KW10R
x
Special Order
These items are not immediately available for pickup at our stores.
We can ship these products to our stores for free in-store pickup.
Items usually arrive at the store within 2 to 7 business days.
ASUS RS700A-E13-RS4U-2KW10 1U Rackmount Barebone Server Dual AMD EPYC 9005 SP5 Supported 24x DDR5 ECC RAM Slots4x Hot-Swap NVMe/SATA/SAS Dual 10GbE 2000W Redundant PSU
$2,999.99
We Build AI Servers and Workstations
Planning an AI deployment or upgrading your compute stack? Our team can help you configure and assemble a system tailored to your performance goals, budget, and deployment environment — from desk-side AI workstations to rack-ready enterprise servers.
Restricted return policy on Servers.
Please see our Return Policy for more info.
Please see our Return Policy for more info.
| Specifications — ASUS RS700A-E13-RS4U | |
|---|---|
| Processor / System Bus | 2 × Socket SP5 (LGA 6096P) AMD EPYC™ 9005 processors (Up to TDP 400W) * TDP support by configuration. |
| Generation | E13 |
| Memory | Total Slots: 24 (12-channel per CPU, 1 DIMM per CPU) Capacity: Total Maximum up to 3072GB Memory Type: DDR5 6400/5600 RDIMM / 3DS RDIMM Memory Size: 128GB, 96GB, 64GB, 32GB RDIMM 128GB, 96GB, 64GB, 32GB 3DS RDIMM * Refer to www.asus.com/support for more information. |
| Expansion Slots | Total 4 expansion slots 2 × PCIe Gen5 x16 (FHHL) 2 × OCP3.0 Gen5 x16 (SFF) |
| Drive Bays | 4 × 2.5"/3.5" hot-swap drive bays Supports 4 × NVMe/SATA/SAS* * HBA/RAID card is required to support SAS hard drives. |
| System Fan | 8 |
| Networking | 1 × Management Port |
| Graphics | Aspeed AST2600 64MB |
| Front I/O Ports | 2 × USB 3.2 Gen1 ports |
| Rear I/O Ports | 2 × USB 3.2 Gen1 ports 1 × Mini-DP port 1 × RJ-45 Management LAN port 1 × Debug port |
| Switch / LEDs | Front: 1 × Power Switch w/ LED 1 × Reset Switch 1 × Location Switch w/ LED 1 × HDD Access LED 1 × Message LED Rear: 1 × Power Switch w/ LED 1 × Location Switch w/ LED 1 × Message LED |
| OS Support | Please find the latest OS support from https://servers.asus.com/support/os |
| Management Solution | On-Board ASMB12-iKVM for KVM-over-IP ASUS Control Center Enterprise (Classic C) (Optional) |
| Regulatory Compliance | BSMI, CE, CB, RCM, FCC (Class A), ISED |
| Dimensions (L × W × H) | 821.7 × 483 × 43.2 mm 32.35" × 19" × 1.7" |
| Form Factor | 1U |
| Weight | Net: 13.81 kg Gross: 16.71 kg |
| Power Supply | 1+1 Redundant 2000W 80 PLUS Titanium/Platinum PSU Rating: 100–127V~ / 220–240V~, 12A/10A (×2), 50/60Hz |
| Environment | Operating temperature: 10℃ ~ 35℃ Non-operating temperature: -40℃ ~ 60℃ Non-operating humidity: 20% ~ 90% (Non-condensing) |
| Optional Items | Security: Dual BMC Module (default) TPM Module (MUST bundle with ASUS server while placing order if required.) Accessory: 1U Front Bezel 1U Height Full Extension Ball Bearing Type Rail Kit Cable Arm (Please consult sales if required.) |
| Note | * SAS support only from SAS HBA/RAID Card. |
| CPU Heatsink / Cooler | 2 × 1U EVAC Heatsink |
| FRU Part List | Motherboard: 90SB0D10-M1XBN0 Front Panel Board: 90SC0TP0-M0XBN1 Backplane: 90SC0TC0-M0XBN1 Riser Card: 90SC0SP0-M0XBN1 DC-SCM Board: 90SC0SI0-M2XBN1 SATA/SAS Cable (BAY1-4): 90SKS000-MPVAN0 NVMe Cable (BAY1-2 OR BAY3-4): 90SKS000-MPJAN0 3.5" HDD Tray: 90SKH000-MPRBN0 1U CPU EVAC: 90SKS000-MQ0AN0 PSU CRPS 2000W TITANIUM: 90SKS000-MJVAN0 1U Full Extension Slide Rail: 90SKR000-M0AAN0 R2P-B Cable Arm: 90SKS000-M23AN0 |
