ASUS ESC8000A-E13P-32WP 4U AMD PLX Server rackmoun Barebone 2x Socket SP5 Sock 24x DDR5 8x hot-swap 2.5in bays 2x 10GbE 3200W PSU
Model #: ESC8000A-E13P-32WP
Item #: SYSASU813P4R
(view)
x
- Store inventory
-
837 Howard Street, CA 94103
415-495-58880 -
2727 S. El Camino Real, CA 94403
650-345-58880 -
510 Lawrence Expressway, Suite 107, CA 94085
650-964-58881 -
3777 Stevens Creek Blvd., CA 95051
408-248-58880 -
5990 Mowry Ave., CA 94560
510-792-58880 -
Disclaimer: Inventory accuracy is not guaranteed. We can do transfers between stores or special order for your convenience.
ASUS ESC8000A-E13P-32WP 4U AMD PLX Server rackmoun Barebone 2x Socket SP5 Sock 24x DDR5 8x hot-swap 2.5in bays 2x 10GbE 3200W PSU
$10,999.99
We Build AI Servers and Workstations
Planning an AI deployment or upgrading your compute stack? Our team can help you configure and assemble a system tailored to your performance goals, budget, and deployment environment — from desk-side AI workstations to rack-ready enterprise servers.
Restricted return policy on Servers.
Please see our Return Policy for more info.
Please see our Return Policy for more info.
| Specifications | |
|---|---|
| Processor / System Bus | 2 × Socket SP5 (LGA 6096) AMD EPYC™ 9005 series processors * Up to 500W cTDP, TDP support varies by configuration |
| Memory | Total Slots: 24 (12 channel per CPU, 12 DIMM per CPU) Capacity: Maximum up to 3TB Memory Type: DDR5 6400/5600 RDIMM Memory Size: 128GB, 96GB, 64GB, 32GB, 16GB RDIMM * Refer to ASUS server AVL for the latest update |
| Expansion Slots | Up to 14 slots Rear: 8 × PCIe x16 for dual-slot GPU cards (Gen5 x16 link, FH/FL) Rear: 5 × PCIe x16 for NIC/BlueField-3 cards (Gen5 x16 link, FH/HL) Front: 1 × PCIe x16 (Gen5 x8 link, FH/HL) |
| Storage | 8 × 2.5" Front Hot-swap Storage Bays Default SKU: Backplane supports up to 8 × NVMe (*MGX compliance) RAID SKU: Backplane supports up to 4 or 6 NVMe drives based on HBA/RAID card model installed 2 × M.2 Socket, supports up to 22110 type (PCIe Gen5 x4 link) (M.2 board supports up to 2 × NVMe) |
| Networking | 2 × 10GbE LAN ports (RJ45, X710-AT2) 1 × Management Port |
| Multi-GPU Support | Please find the latest GPU support from https://servers.asus.com/support/gpu |
| Front I/O Ports | 1 × Mini DisplayPort 2 × USB 5Gbps ports 1 × Debug port |
| Rear I/O Ports | 1 × USB 5Gbps port 2 × RJ-45 LAN ports 1 × RJ-45 Management LAN port |
| Switch / LED | Front: 1 × Power switch/LED Front: 1 × Location switch/LED Front: 1 × Message LED Front: 1 × Clear CMOS switch Front: 1 × Reset Switch Front: 2 × M.2 LEDs Front: 2 × LAN LEDs Front: 1 × Q-code/Port 80 LED Rear: 1 × Power switch/LED Rear: 1 × Location switch/LED Rear: 1 × Message LED |
| OS Support | Please find the latest OS support from https://servers.asus.com/support/os |
| Management Solution | ASUS Control Center Enterprise (in-band) ASMB12-iKVM (out-of-band / BMC AST2600) |
| Regulatory Compliance | BSMI, CB, CE, FCC (Class A), RCM |
| Dimensions | 800mm × 439.5mm × 175mm 31.5" × 17.3" × 6.9" |
| Form Factor | 4U |
| Weight | Net Weight: 42 Kg Gross Weight: 44.23 Kg |
| Power Supply | 3+1 redundant 3200W 80 PLUS Titanium power supply 220–240 Vac, 16A (×4) 50/60Hz |
| Environment | Operating temperature: 10°C ~ 35°C Non-operating temperature: -40°C ~ 60°C Non-operating humidity: 20% ~ 95% (Non-condensing) * For operating temperatures above 30°C, please contact your local sales representative |
| Field-Replaceable-Unit Part List | Motherboard: 90SB0D90-M5XBN0 GPU Fan module 80×80×80mm: 90SKS000-MR0BN0 System Fan module 80×80×80mm: 90SKS000-MR1BN0 2U Standard CPU heatsink: 90SKS000-M4LAN0 HDD Tray Toolless ASY: 90SKH000-MPPBN0 3200W Titanium PSU: 90SKS000-MMCBN0 1M Rail Kit: 90SKS000-MR2BN0 2U Rail Kit (supports cable arm): 90SKS000-MR3BN0 Cable Arm: 90SKS000-MR4BN0 9670-24I RAID Cable Kit: 90SKS000-MQXBN0 9560-16I RAID Cable Kit: 90SKS000-MQYBN0 MiniDP to VGA Dongle: 90SKS000-MU3BN0 |
