ASUS Pro WS W890E-SAGE SE SSI EEB Motherboard Intel Socket LGA4710-2 Intel W890 Chipset 8x DDR5 DIMM Slots Max 2048GB
Model #: ASUS Pro WS W890E-SAGE SE
Item #: MOTASUW89SER
(view)
x
- Store inventory
-
837 Howard Street, CA 94103
415-495-58884 -
2727 S. El Camino Real, CA 94403
650-345-58884 -
510 Lawrence Expressway, Suite 107, CA 94085
650-964-58884 -
3777 Stevens Creek Blvd., CA 95051
408-248-58884 -
5990 Mowry Ave., CA 94560
510-792-58884 -
Disclaimer: Inventory accuracy is not guaranteed. We can do transfers between stores or special order for your convenience.
ASUS Pro WS W890E-SAGE SE SSI EEB Motherboard Intel Socket LGA4710-2 Intel W890 Chipset 8x DDR5 DIMM Slots Max 2048GB
$1,199.99
| General Information | |
| Product Type | Workstation Motherboard |
| Product Series | PRO |
| Brand Name | Asus |
| Manufacturer | ASUS Computer International |
| Product Model | WS W890E-SAGE SE |
| Product Name | Pro WS W890E-SAGE SE Workstation Motherboard |
| Manufacturer Part Number | ASUS Pro WS W890E-SAGE SE |
| Manufacturer Website Address | http://usa.asus.com |
| Technical Information | |
| AI-powered | Yes |
| Processor & Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | W890 |
| Processor Socket | Socket LGA-4710-2 |
| Processor Supported | Xeon |
| Total Processor Supported | 1 |
| Memory | |
| Number of Memory Slots | 8 |
| Memory Form Factor | DIMM |
| Memory Form Factor | UDIMM |
| Memory Form Factor | RDIMM |
| Memory Technology | DDR5 SDRAM |
| Error Checking | ECC |
| Maximum Memory Supported | 4 TB |
| I/O Controller | |
| RAID Supported | Yes |
| RAID Levels | 0 |
| RAID Levels | 1 |
| RAID Levels | 5 |
| RAID Levels | 10 |
| Controller Type | Serial ATA/600 |
| Video | |
| Onboard Video | CPU Dependent Video |
| Audio | |
| Audio Channels | 7.1 |
| Network & Communication | |
| Gigabit Ethernet | Yes |
| Wireless LAN | No |
| 10Gigabit Ethernet | Yes |
| 2.5Gigabit Ethernet | Yes |
| I/O Expansions | |
| Number of PCI Express x16 Slots | 8 |
| PCI Express Standard | PCI Express 5.0 |
| PCI Express Standard | PCI Express 4.0 |
| Total Number of PCI Express Slots | 8 |
| Total Number of Expansion Slots | 8 |
| Interfaces/Ports | |
| VGA | Yes |
| Number of Network (RJ-45) Ports | 3 |
| DisplayPort | Yes |
| Total Number of USB Ports | 8 |
| Number of USB 3.2 Gen 2 Type-A Ports | 6 |
| Onboard Interfaces | |
| Number of SATA Interfaces | 4 |
| Total Number of Onboard USB Ports | 6 |
| Number of Onboard USB 2.0 Ports | 4 |
| Number of M.2 Interfaces | 4 |
| Physical Characteristics | |
| Height | 2" |
| Width | 12" |
| Depth | 13" |
| Form Factor | SSI EEB |
| Weight (Approximate) | 7.50 lb |
| Miscellaneous | |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
