ASUS PRIME X870-P WIFI ATX AM5 Motherboard Ryzen 9000/7000 Socket AM5 LGA 17184 4x DDR5 DIMM 1 PCIe 5.0 x16 1 PCIe 4.0 x1
Model #: PRIME X870-P WIFI
Item #: MOTASUX87PWR
(view)
x
- Store inventory
-
837 Howard Street, CA 94103
415-495-58880 -
2727 S. El Camino Real, CA 94403
650-345-58881 -
510 Lawrence Expressway, Suite 107, CA 94085
650-964-58881 -
3777 Stevens Creek Blvd., CA 95051
408-248-58885 -
5990 Mowry Ave., CA 94560
510-792-58880 -
Disclaimer: Inventory accuracy is not guaranteed. We can do transfers between stores or special order for your convenience.
ASUS PRIME X870-P WIFI ATX AM5 Motherboard Ryzen 9000/7000 Socket AM5 LGA 17184 4x DDR5 DIMM 1 PCIe 5.0 x16 1 PCIe 4.0 x1
$239.99
| Specifications | |
|---|---|
| Model | PRIME X870-P WIFI |
| CPU | AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors * Refer to https://www.asus.com/support/download-center/ for CPU support list. |
| Chipset | AMD X870 Chipset |
| Memory | 4 × DIMM slots, Max. 256GB, DDR5 Supports up to 8000+ MT/s (OC) with Ryzen™ 9000 & 8000 & 7000 Series Processors, ECC and Non-ECC Un-buffered DIMM Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO™) ASUS Enhanced Memory Profile (AEMP) * Adjustments will be made based on the specifications of mass-produced memory products available on the market. * Supported memory types, data rate, and number of DRAM modules vary depending on CPU and memory configuration. Refer to CPU/Memory Support list or visit https://www.asus.com/support/download-center/. * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. |
| Graphics | 1 × HDMI™ port 2 × USB4® (40Gbps) ports support USB Type-C® display outputs * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. ** HDMI 2.1 supports 4K@60Hz. *** USB4® display outputs support max. 4K@60Hz as specified in DisplayPort 1.4a. *** VGA resolution support depends on processors' or graphic cards' resolution. |
| Expansion Slots | Ryzen™ 9000 & 7000 Series: 1 × PCIe 5.0 x16 slot (supports x16 mode) Ryzen™ 8000 Series: 1 × PCIe 4.0 x16 slot (supports x8/x4 mode) AMD X870 Chipset: 3 × PCIe 4.0 x16 slots (support x1 mode) * Please check the PCIe bifurcation table at https://www.asus.com/support/FAQ/1037507/. ** Specifications vary by CPU types. *** PCIEX16(G4)_1 shares bandwidth with M.2_2; disabled when M.2_2 is active. *** PCIEX16(G4)_2 and PCIEX16(G4)_3 share bandwidth with M.2_3; both disabled when M.2_3 is active. * Refer to https://www.asus.com/support/download-center/ for supported peripherals. |
| Storage | Total: 4 × M.2 slots + 2 × SATA 6Gb/s ports Ryzen™ 9000 & 7000 Series: M.2_1 (Key M), type 2280 — PCIe 5.0 x4 Ryzen™ 8000 Series: M.2_1 (Key M), type 2280 — PCIe 4.0 x4 AMD X870 Chipset: M.2_2 (Key M), type 2242/2260/2280 — PCIe 4.0 x4 M.2_3 (Key M), type 2280 — PCIe 4.0 x4 M.2_4 (Key M), type 2280 — PCIe 3.0 x2 2 × SATA 6Gb/s ports AMD RAIDXpert2: Ryzen™ 9000 — RAID 0/1/5/10; Ryzen™ 8000 — RAID 0/1; Ryzen™ 7000 — RAID 0/1/10 * PCIEX16(G4)_1 shares bandwidth with M.2_2; disabled when M.2_2 is active. ** PCIEX16(G4)_2 and PCIEX16(G4)_3 share bandwidth with M.2_3; both disabled when M.2_3 is active. *** M.2_4 shares bandwidth with SATA6G_1 and SATA6G_2; M.2_4 disabled when either SATA port is active. |
| Ethernet | 1 × Realtek 2.5Gb Ethernet ASUS LANGuard |
| Wireless & Bluetooth | Wi-Fi 7 (802.11be), 2×2, supports 2.4/5/6GHz, 160MHz bandwidth, up to 2.9Gbps Bluetooth® v5.4 * Wi-Fi features may vary by OS. Windows 11 24H2 or later required for full Wi-Fi 7; Windows 11 21H2/22H2/23H2 supports Wi-Fi 6E only. ** Wi-Fi 6GHz frequency band regulatory may vary between countries. *** Bluetooth version may vary; refer to Wi-Fi module manufacturer's website for latest specifications. |
| USB — Rear (10 ports) | 2 × USB4® 40Gbps (2 × Type-C®) 1 × USB 10Gbps (1 × Type-A) 3 × USB 5Gbps (3 × Type-A) 4 × USB 2.0 (4 × Type-A) * USB Type-C® power delivery output: max. 5V/3A. |
| USB — Front (7 ports) | 1 × USB 10Gbps connector (supports Type-C®) 1 × USB 5Gbps header (2 additional USB 5Gbps ports) 2 × USB 2.0 headers (4 additional USB 2.0 ports) |
| Audio | Realtek 7.1 Surround Sound HD Audio CODEC Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Supports up to 24-Bit/192kHz playback Features: Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required for 7.1 Surround Sound output. |
| Back Panel I/O | 2 × USB4® 40Gbps (2 × Type-C®) 1 × USB 10Gbps (1 × Type-A) 3 × USB 5Gbps (3 × Type-A) 4 × USB 2.0 (4 × Type-A) 1 × HDMI™ port 1 × Wi-Fi module 1 × Realtek 2.5Gb Ethernet port 3 × Audio jacks 1 × BIOS FlashBack™ button |
| Internal I/O — Fan & Cooling | 1 × 4-pin CPU Fan header 1 × 4-pin CPU OPT Fan header 1 × 4-pin AIO Pump header 4 × 4-pin Chassis Fan headers |
| Internal I/O — Power | 1 × 24-pin Main Power connector 2 × 8-pin +12V CPU Power connectors |
| Internal I/O — Storage | 4 × M.2 slots (Key M) 2 × SATA 6Gb/s ports |
| Internal I/O — USB | 1 × USB 10Gbps connector (supports Type-C®) 1 × USB 5Gbps header (2 additional ports) 2 × USB 2.0 headers (4 additional ports) |
| Internal I/O — Miscellaneous | 3 × Addressable Gen 2 headers 1 × Clear CMOS header 1 × COM Port header 1 × Front Panel Audio header (F_AUDIO) 1 × S/PDIF Out header 1 × SPI TPM header (14-1 pin) 1 × 10-1 pin System Panel header |
| Special Features | 5X Protection III: DIGI+ VRM (DrMOS), LANGuard, Overvoltage Protection, SafeSlot, Stainless-Steel Back I/O Q-Design: M.2 Q-Latch, PCIe Slot Q-Release, Q-Antenna, Q-Dashboard, Q-DIMM, Q-LED Core, Q-Slot Thermal Solution: Flexible M.2 heatsink, VRM heatsink design EZ DIY: BIOS FlashBack™ button/LED, ProCool, Pre-mounted I/O shield, SafeSlot Aura Sync: Addressable Gen 2 headers |
| Software | Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4 with AI Cooling II, Power Saving) ASUS DriverHub / ASUS GlideX / TurboV Core / ASUS CPU-Z UEFI BIOS: ASUS CrashFree BIOS 3, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode, ASUS MyHotkey |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Manageability | WOL by PME, PXE |
| Accessories | 2 × SATA 6Gb/s cables 1 × ASUS WiFi Q-Antenna 1 × M.2 rubber package 2 × Screw packages for M.2 SSD 1 × Quick start guide |
| Operating System | Windows® 11 |
| Form Factor | ATX 12 in. × 9.6 in. (30.5 cm × 24.4 cm) |
